Kubota KX91-3S, KX101-3, KX121-3S, KX161-3S Excavator Repair Manual
$28.00
| đźšś Equipment | |||
|---|---|---|---|
| Brand | Kubota | ||
| Type | Excavator | ||
| Model | KX91-3S, KX101-3, KX121-3S, KX161-3S | ||
| đź“„ Documents | |||
| Language | English | ||
| Format | |||
| Title | Serial | Publication No. | Pages |
| Repair Manual | Europe | 97899-61260 | 206 |
| Repair Manual – Angle Dozer | Japan | 97899-60550 | 24 |
- Description
- Additional information
- Table of Content
- Specification
- Buyer Questions & Answers
- Reviews (0)
The Kubota KX91-3S, KX101-3, KX121-3S, and KX161-3S Mini Excavators are versatile and powerful machines built for a variety of excavation, trenching, and material-handling applications. Designed with Kubota’s proven diesel engines, advanced hydraulics, and robust construction, these models provide the performance, reliability, and efficiency required by contractors and operators working in demanding environments.
The KX91-3S is a compact machine weighing about 3.2 tonnes, powered by a 28 hp engine and capable of digging depths up to 3.17 meters. The KX101-3 offers greater reach and performance, weighing approximately 3.59 tonnes and delivering 30 hp with a digging depth of around 3.3 meters. The KX121-3S steps up further with a 39 hp engine, an operating weight of about 4.1 tonnes, and a digging depth of nearly 4 meters. The largest in this group, the KX161-3S, weighs over 5.2 tonnes, powered by a 47 hp engine, with a digging depth of 4 meters and a reach of up to 6 meters. Across the range, transport widths vary between 1.55 meters and 1.96 meters, allowing excellent maneuverability while maintaining stability for heavy work.
The workshop repair manual provides detailed servicing instructions for all models, covering the engine, hydraulic system, cylinders, pumps, control valves, swivel joints, travel and swing motors, electrical system, and cab components. It includes detailed diagrams, wiring and hydraulic schematics, lubrication guides, torque specifications, and troubleshooting procedures, ensuring accurate diagnostics and professional maintenance for sustained machine performance.
Key Highlights
- KX91-3S: 3.2 t operating weight, 28 hp engine, 3.17 m digging depth
- KX101-3: 3.6 t operating weight, 30 hp engine, 3.3 m digging depth, 5.4 m reach
- KX121-3S: 4.1 t operating weight, 39 hp engine, 4 m digging depth
- KX161-3S: 5.2 t operating weight, 47 hp engine, 4 m digging depth, 6 m reach
- Transport widths: 1.55–1.96 m for stability and access to confined spaces
- Bucket breakout forces exceeding 9,000–11,000 lbs depending on model
- Workshop manual includes hydraulic and electrical schematics, torque values, and lubrication charts
- Coverage of engines, hydraulics, pumps, valves, travel/swing motors, and cab systems
- Designed for efficient servicing, reliability, and long-term durability
| Publication | 97899-61260, 97899-60550 |
|---|
Table of Content
đź“™ Table of Contents – Publication Number 97899-61260
I General
II Machine body
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .II-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .II-S-1
III Engine
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .III-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .III-S-1
IV Hydraulic System
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IV-M-1
• Service Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IV-S-1
V. ELECTRICAL SYSTEM
• Mechanism Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V-M-1
• Service Section. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V-S-1
KX91-3S, KX101-3, KX121-3S, KX161-3S
Your KUBOTA dealer is always ready to help so that your excavator offers the best performance. After having carefully read this manual, you will realize that much of the routine maintenance can be done by yourself. Machines must be disassembled and assembled efficiently and safely. It is very important to thoroughly understand the construction and function of the machine, to make all appropriate preparations, and start operations according to the specified working procedures in this workshop repair manual.
Specification
| Specification | Kubota KX91-3S Mini Excavator | Kubota KX101-3 Mini Excavator | Kubota KX121-3S Mini Excavator | Kubota KX161-3S Mini Excavator |
|---|---|---|---|---|
| Operating Weight | ~3,225 kg (7,110 lb):contentReference[oaicite:0]{index=0} | ~3,590 kg (3.59 t):contentReference[oaicite:1]{index=1} | ~4,112 kg (9,063 lb):contentReference[oaicite:2]{index=2} | ~5,230 kg (11,532 lb):contentReference[oaicite:3]{index=3} |
| Engine Power | ~28 hp net (D1503):contentReference[oaicite:4]{index=4} | ~30 hp (approx.):contentReference[oaicite:5]{index=5} | 39 hp net / 40.5 hp gross:contentReference[oaicite:6]{index=6} | 47 hp net (V2403-M):contentReference[oaicite:7]{index=7} |
| Max Digging Depth | ~3.17 m (10 ft 5 in):contentReference[oaicite:8]{index=8} | ~3.3 m:contentReference[oaicite:9]{index=9} | ~4 m (12 ft):contentReference[oaicite:10]{index=10} | ~4 m (13 ft):contentReference[oaicite:11]{index=11} |
| Max Reach | ~5.0 m (17 ft):contentReference[oaicite:12]{index=12} | ~5.4 m:contentReference[oaicite:13]{index=13} | ~5 m (18 ft):contentReference[oaicite:14]{index=14} | ~6 m (20 ft):contentReference[oaicite:15]{index=15} |
| Transport Width | ~1.55 m:contentReference[oaicite:16]{index=16} | Not specified | ~1.70 m:contentReference[oaicite:17]{index=17} | ~1.96 m:contentReference[oaicite:18]{index=18} |
