Kubota KH66, KH91, KH101, KH105 Excavator Workshop Repair Manual

Kubota KH66, KH91, KH101, KH105 Excavator Workshop Repair Manual

$31.00

🚜 Equipment
Brand	Kubota
Type	Excavator
Model	KH66, KH91, KH101, KH105
📄 Documents
Type	Repair Manual
Publication	97899-61970
Language	English
Format	PDF
No of Pages	740

The Kubota KH66, KH91, KH101, and KH105 Mini Excavators are part of Kubota’s early compact excavator lineup, engineered to deliver reliable performance, simple operation, and straightforward servicing. With operating weights ranging from approximately 2.8 tonnes (KH66) to over 3.5 tonnes (KH101), these machines are designed to handle light-to-medium excavation projects in construction, utilities, and landscaping. Their compact transport widths of about 1.5 meters allow access to confined work areas while maintaining stability during digging and lifting operations.

The KH66 is equipped with a bucket capacity of about 0.07 m³ and compact dimensions for small job sites. The KH91, with an operating weight of ~7,750 lbs (3,517 kg), offers increased durability and lifting power. The KH101 continues the line with a 3.5-ton weight class, providing enhanced digging performance. While detailed data for the KH105 is limited, it represents an incremental upgrade with further refinements in capacity and reliability. All models were built with Kubota diesel engines, known for their durability, fuel efficiency, and ease of maintenance.

The workshop repair manual provides complete service coverage for these machines, including general maintenance, the machine body, hydraulic systems, electrical systems, and engine servicing. Detailed step-by-step procedures, torque specifications, hydraulic schematics, wiring diagrams, and lubrication charts are included, enabling precise diagnostics and professional-level repairs to keep these excavators operating at peak performance.

Key Highlights

Kubota KH66: ~2.8 t operating weight, 1.51 m transport width, 0.07 m³ bucket capacity
Kubota KH91: ~3.5 t operating weight, ~1.52 m transport width for stable digging
Kubota KH101: ~3.5 t class machine with improved capacity and durability
Kubota KH105: Later model in the KH series, refined for added reliability
Compact transport width (~1.5 m) across the series for confined site access
Powered by proven Kubota diesel engines for efficiency and reliability
Manual coverage: machine body, hydraulics, electrical system, and engine
Includes hydraulic and electrical schematics, torque values, and lubrication guides
Designed for straightforward servicing and long-term durability

Table of Content

📙 Table of Contents

Front Cover

Front Cover

Contents

Contents

1. General

1. General

2. Machine Body

2. Machine Body

3. Hydraulic System

3. Hydraulic System

4. Electrical System

4. Electrical System

5. Engine

5. Engine

Back Cover

Back Cover
