Ford Versatile D118, D145 and G125 Tractors Repair Manual
$20.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Tractor |
| Model | D118, D145 and G125 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 40011831 |
| Language | English |
| Format | |
| No of Pages | 88 |
The Ford Versatile D118, D145, and G125 tractors were among the first generation of Versatile 4WD articulated tractors, produced in the late 1960s and early 1970s. These models featured robust Cummins and Ford engines ranging from 135 hp in the D118 to 180 hp in the D145, with the G125 powered by a 165 hp Ford V-8 gasoline engine. Built for durability and versatility, these tractors introduced farmers to high-horsepower 4WD machines capable of handling heavy tillage and demanding fieldwork with ease.
This official repair manual provides complete factory service information for the D118, D145, and G125 tractors. It is organized into detailed sections covering general specifications, the fuel and air system, clutch, transmission, PTO, brake system, axles, hydraulics, and electrical systems. Each chapter includes step-by-step service procedures, troubleshooting guides, torque specifications, wiring diagrams, and hydraulic schematics to ensure accurate and reliable servicing.
With its coverage of both diesel and gasoline-powered models, this manual is essential for technicians, operators, and owners seeking to maintain
Table of Content
📙 Table of Contents
Table Of Contents
- Table of Contents
General Specifications
- General Specifications
Fuel And Air System
- Fuel and Air System
Clutch
- Clutch
Transmission
- Transmission
Power Take-Off
- Power Take-Off
Brake
- Brake
Axles
- Axles
Hydraulic System
- Hydraulic System
Electrical System
- Electrical System
Specification
| Specification | D-118 | D-145 | G-125 |
|---|---|---|---|
| Years Produced | 1967 – 1971 :contentReference[oaicite:0]{index=0} | ≈ 1969 – 1971 :contentReference[oaicite:1]{index=1} | 1967 – 1968 :contentReference[oaicite:2]{index=2} |
| Engine Manufacturer / Type | Cummins V-6, 5.8 L 6-cylinder diesel :contentReference[oaicite:3]{index=3} | Cummins V-8 Series, 7.7 L diesel (≈ 470 cu in) :contentReference[oaicite:4]{index=4} | Ford C4PC V-8, 6.4 L gasoline :contentReference[oaicite:5]{index=5} |
| Gross Engine Power | 135 hp (100.7 kW) :contentReference[oaicite:6]{index=6} | 180 hp (134.2 kW) :contentReference[oaicite:7]{index=7} | 165 hp (123.0 kW) :contentReference[oaicite:8]{index=8} |
| Transmission | 9-speed gear transmission :contentReference[oaicite:9]{index=9} | Same style 9-speed gear transmission :contentReference[oaicite:10]{index=10} | 9-speed gear transmission :contentReference[oaicite:11]{index=11} |
| Hydraulic System (Type / Pressure / Valves / Pump Flow) | Open-center; pressure ~ 1,750 psi; 3 valves; pump flow ~ 12.5 gpm (early), later ~ 16.5 gpm :contentReference[oaicite:12]{index=12} | Same open-center hydraulic system; similar pressure & valve count :contentReference[oaicite:13]{index=13} | Same open-center hydraulics; pressure ~ 1,750 psi; 3 valves; pump flow ~ 12.5-16.5 gpm :contentReference[oaicite:14]{index=14} |
| Fuel Capacity | ≈ 54 gal (≈ 204 L) :contentReference[oaicite:15]{index=15} | Same 54 gal tank in that series :contentReference[oaicite:16]{index=16} | 54 gal ≈ 204 L :contentReference[oaicite:17]{index=17} |
| Rear Hitch / Lift Capacity (24 in / 610 mm) | ≈ 6,000 lb (≈ 2,721 kg) lift at 24″ :contentReference[oaicite:18]{index=18} | Same ~ 6,000 lb class :contentReference[oaicite:19]{index=19} | ≈ 6,000 lb at 24″ :contentReference[oaicite:20]{index=20} |
| Dimensions & Weight | Wheelbase ~ 120 in (≈ 304 cm); weight ~ 12,650 lb (≈ 5,738 kg) :contentReference[oaicite:21]{index=21} | Weight ~ 14,550 lb (≈ 6,599 kg) :contentReference[oaicite:22]{index=22} | Weight ~ 12,100 lb (≈ 5,488 kg) :contentReference[oaicite:23]{index=23} |
| Power Take-Off (PTO) | Rear live PTO, Type 1000 rpm at ~ 2,700 rpm engine speed :contentReference[oaicite:24]{index=24} | Rear Type 1000 live PTO :contentReference[oaicite:25]{index=25} | Rear live PTO, Type 1000 rpm @ ~ 2,700 rpm :contentReference[oaicite:26]{index=26} |
| Other Features | 4WD; articulated power steering; planetary final drives; optional cab; drum brakes; open operator station; electrical ground negative; alternator ~ 40 amps :contentReference[oaicite:27]{index=27} | Same feature set typical of Versatile 100-series tractors :contentReference[oaicite:28]{index=28} | Same mechanical / operator features; V-8 gasoline engine; same 4WD, planetary drive, etc. :contentReference[oaicite:29]{index=29} |
