Ford Versatile 1156 Tractor Repair Manual
$33.00
| đźšś Equipment | |
|---|---|
| Brand | FORD |
| Type | Tractor |
| Model | 1156 |
| đź“„ Documents | |
| Type | Repair Manual |
| Publication | 40115610 |
| Language | English |
| Format | |
| No of Pages | 560 |
The Ford Versatile 1156 tractor was produced from 1986 to 1991 as one of the most powerful articulated 4WD tractors of its time. Powered by the Cummins KTA-1150C 18.8L six-cylinder turbocharged diesel engine, the Versatile 1156 delivers 470 horsepower, making it ideal for the largest tillage, land development, and heavy drawbar applications. With a 400-gallon fuel tank, high-capacity closed-center hydraulics, and a rugged articulated frame, the 1156 was engineered for durability and nonstop productivity in demanding agricultural environments.
This comprehensive repair manual provides complete factory service coverage for the Ford Versatile 1156 tractor. Organized into logical sections, it covers the engine systems, fuel system, electrical system, clutch, transmission and brake systems, driveline, axles, hydraulics, steering, cab and environmental controls, wheels and tires, and complete specifications. Each chapter includes step-by-step repair procedures, troubleshooting charts, wiring diagrams, hydraulic schematics, and torque values to ensure accurate and efficient servicing.
From overhauling the 8-speed transmission and servicing the closed-center load-sensing hydraulic system (55 gpm total flow at 2,500 psi) to maintaining the Cummins 18.8L diesel engine, this manual provides the detailed information technicians, operators, and owners need to keep the Versatile 1156 operating at factory standards. With complete coverage of cab comfort, structural components, and wheel and tire setups, the manual ensures long service life and reliable operation.
Key Highlights
- Covers the Ford Versatile 1156 articulated 4WD tractor (470 hp Cummins KTA-1150C diesel)
- Step-by-step service instructions for engine, fuel, clutch, transmission, and brake systems
- Comprehensive coverage of driveline, axles, hydraulics, and steering systems
- Closed-center hydraulic system with ~55 gpm total flow and ~2,500 psi working pressure
- Cab, frame, seating, and environmental systems repair procedures included
- Service sections for wheels, tires, and tractor weighting
- Electrical system troubleshooting with full wiring diagrams
- Factory torque charts, schematics, and separating/reassembly instructions
Table of Content
đź“™ Table of Contents
Table Of Contents Volume 1
- Table of Contents Volume 1
Section 1: Engine Systems
- Section 1: Engine Systems
Section 2: Fuel System
- Section 2: Fuel System
Section 3: Electrical System
- Section 3: Electrical System
Section 4: Clutch
- Section 4: Clutch
Section 5: Transmission And Brake System
- Section 5: Transmission and Brake System
Table Of Contents Volume 2
- Table of Contents Volume 2
Section 6: Driveline System
- Section 6: Driveline System
Section 7: Axles
- Section 7: Axles
Section 8: Hydraulic System
- Section 8: Hydraulic System
Section 9: Steering System
- Section 9: Steering System
Section 11: Cab, Seat, Frame And Environmental
- Section 11: Cab, Seat, Frame and Environmental
Section 13: Wheels, Tires And Weighting
- Section 13: Wheels, Tires and Weighting
Section 17: Specifications
- Section 17: Specifications
Specification
| Specification | Versatile 1156 |
|---|---|
| Years Produced | 1986 – 1991 |
| Engine Manufacturer / Model | Cummins KTA-1150C |
| Engine Type | 6-cylinder, liquid-cooled, turbocharged diesel |
| Displacement | 18.8 L (1,150 cu in) |
| Gross Power | 470 hp (350.5 kW) |
| Transmission | 8-forward / 4-reverse gear transmission |
| Fuel Tank Capacity | 400 gal (1,514 L) |
| Hydraulic System Type | Closed-center, load-sensing |
| Hydraulic Capacity | 100 gal (378 L) |
| Pump Flow | 27.7 gpm (105 L/min); total flow ~55 gpm |
| Relief Pressure | 2,500 psi (172 bar) |
| Remote Valves | 5 |
| PTO | Rear PTO, 1000 rpm |
| Wheelbase | 140 in (355 cm) |
| Operating Weight | 25,500 lb (11,566 kg) |
| Tires | 30.5-32 (front & rear) |
| Brakes | Hydraulic disc & caliper |
| Steering | Hydrostatic articulated power steering |
| Electrical System | 12-volt, negative ground, alternator 90 amps |
| Cab | Standard cab with air-conditioning & AM/FM cassette |
