Ford New Holland 1920, 2120 Tractor Repair Manual

Ford New Holland 1920, 2120 Tractor Repair Manual

Price range: $20.00 through $34.00

🚜 Equipment
Brand	FORD
Type	Tractors
Model	1920, 2120
📄 Documents
Language	English
Format	PDF
Title	Publication No.	Pages
Repair Manual	40192020	658
Supplement Repair Manual	40192022	28

The Ford New Holland 1920 and 2120 tractors are versatile compact utility machines produced between 1987 and 1995, designed for agricultural, landscaping, and light construction applications. Powered by reliable Shibaura 4-cylinder diesel engines (2.0 L in the 1920 and 2.3 L in the 2120), these tractors deliver gross power ratings of 33 hp and 42 hp respectively, with PTO outputs of 28–34 hp for efficient implement operation.

This repair manual provides complete coverage of both models, including engine, fuel, electrical, transmission, PTO, differential, hydraulics, steering, axles, and chassis systems. Detailed sections guide the technician through servicing clutches, brakes, hydraulics, and wheels, as well as separating the tractor for major overhauls. Supplements expand coverage with additional procedures for fuel and engine systems, and transmission service specific to the 2120 model.

The manual is structured for professional repair and maintenance, offering serial number identification, safety precautions, service techniques, torque values, and wiring diagrams. Whether maintaining the rear Type I hitch (1,800–2,500 lb lift capacity), troubleshooting the open-center hydraulic system, or servicing the mechanical shuttle transmission, this manual ensures accurate and efficient repairs.

Key Highlights

Comprehensive coverage for Ford/New Holland 1920 (33 hp) and 2120 (42 hp) tractors
Step-by-step procedures for engines, fuel systems, clutches, and transmissions
Power Take-Off (PTO) repair and adjustment procedures
Hydraulic system servicing with flow, capacity, and troubleshooting details
Rear axle, differential, and wet disc brake overhaul instructions
Steering and front axle repair for both 2WD and MFWD configurations
Wheel, tire, and chassis separation procedures for major service operations
Includes supplements covering engine, fuel, and transmission updates

Publication	40192020, 40192022

Table of Content

📙 Table of Contents

New Holland 1920, 2120 Repair Manual

New Holland 1920, 2120 Repair Manual
- Foreword
- Production Date Codes and Serial Numbers
- Safety Precautions
- Service Techniques
- PART ONE, ENGINE SYSTEMS MODELS 1920 AND 2120
- PART TWO, FUEL SYSTEM MODELS 1920-2120
- PART THREE, ELECTRICAL SYSTEMS MODEL 1920-2120
- PART FOUR, CLUTCHES
- PART FIVE, TRANSMISSION SYSTEMS
- PART SIX, POWER TAKE-OFF SYSTEMS
- PART SEVEN, DIFFERENTIAL, REAR AXLE AND BRAKES
- PART EIGHT, HYDRAULIC SYSTEM
- PART NINE, STEERING SYSTEM
- PART TEN, FRONT AXLE AND RELATED PARTS
- PART ELEVEN, WHEELS AND TIRES
- PART TWELVE, SEPARATING THE TRACTOR MODEL 1920-2120

Supplement To New Holland 1920, 2120 Repair Manual

Supplement to New Holland 1920, 2120 Repair Manual
- SUPPLEMENT TO PART ONE, ENGINE SYSTEMS
- SUPPLEMENT TO PART TWO, FUEL SYSTEMS
- SUPPLEMENT INDEX

Supplement To Ford Tractor 2120 Repair Manual

Supplement to Ford Tractor 2120 Repair Manual
- Supplement Introduction
- SUPPLEMENT TO PART FIVE, TRANSMISSION SYSTEMS

Specification

Specification	1920	2120
Years Produced	1987 – 1995	1987 – 1995
Gross Engine Power	33.3 hp (24.8 kW) :contentReference[oaicite:0]{index=0}	42.6 hp (31.8 kW) :contentReference[oaicite:1]{index=1}
Net Engine Power	32 hp (23.9 kW) :contentReference[oaicite:2]{index=2}	40 hp (29.8 kW) :contentReference[oaicite:3]{index=3}
PTO Power (Claimed)	28.5 hp (21.3 kW) :contentReference[oaicite:4]{index=4}	34.5 hp (25.7 kW) :contentReference[oaicite:5]{index=5}
Engine Type & Displacement	Shibaura 2.0 L, 4-cylinder diesel :contentReference[oaicite:6]{index=6}	Shibaura 2.3 L, 4-cylinder diesel :contentReference[oaicite:7]{index=7}
Transmission	12-speed gear / 12-speed mechanical shuttle; 2WD or MFWD 4WD :contentReference[oaicite:8]{index=8}	12-speed gear / 12-speed power shuttle; 2WD or MFWD 4WD :contentReference[oaicite:9]{index=9}
Fuel Capacity	9.8 gal (37.1 L) :contentReference[oaicite:10]{index=10}	11.1 gal (42.0 L) :contentReference[oaicite:11]{index=11}
Hydraulic System Capacity / Flow	7.7 gal (29.1 L); pump flow ~7.8 gpm (29.5 lpm); total flow ~10.6 gpm (40.1 lpm); steering flow ~2.8 gpm (10.6 lpm) :contentReference[oaicite:12]{index=12}	Open center; pump ~9.3 gpm (35.2 lpm); total ~12.1 gpm (45.8 lpm); steering flow ~2.8 gpm (10.6 lpm) :contentReference[oaicite:13]{index=13}
Rear Hitch / Lift Capacity	Rear Type I hitch; rear lift (at 24″/610 mm) ~1,881 lb (853 kg) :contentReference[oaicite:14]{index=14}	Rear Type I hitch; rear lift (at 24″/610 mm) ~2,574 lb (1,167 kg) :contentReference[oaicite:15]{index=15}
Dimensions & Weight	Wheelbase: 69.9 in (177 cm); Weight: ~2,849-3,069 lb (≈1,293-1,392 kg); Front tire 5.50-16; Rear tire 13.6-24 :contentReference[oaicite:16]{index=16}	Wheelbase: 74.8 in (189 cm); Weight: ~3,572-3,858 lb (≈1,620-1,749 kg); Front tire 6.00-16; Rear tire 13.6-28 :contentReference[oaicite:17]{index=17}
Mechanical Features / Others	2- or 4-wheel drive; power steering; wet disc brakes; two-post ROPS; PTO live optional; Rear PTO type 540; open-center hydraulics :contentReference[oaicite:18]{index=18}	2- or 4-wheel drive; power steering; wet disc brakes; two-post ROPS (optional FOPS canopy); independent PTO; Rear PTO type 540; open-center hydraulics :contentReference[oaicite:19]{index=19}
Electrical	Ground negative; 12 V battery system :contentReference[oaicite:20]{index=20}	Ground negative; 12 V battery system :contentReference[oaicite:21]{index=21}
