Ford A-62, A-64, A-66 Wheel Loaders Repair Manual
$34.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Backhoe Loader Tractor |
| Model | A-62, A-64, A-66 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 4006230 |
| Language | English |
| Format | |
| No of Pages | 712 |
The Ford A-62, A-64, and A-66 Wheel Loaders are heavy-duty articulated loaders built for construction, quarry, and industrial applications. These machines combine robust diesel engines with powerful hydraulics, delivering high breakout force, stable loader performance, and dependable operation in demanding environments. With horsepower ratings ranging from 103 hp (A-62) to 160 hp (A-66), this series provides a versatile lineup to match different job site requirements.
The Ford A-62 is equipped with a 4.4L 4-cylinder diesel producing approximately 103 hp, with an operating weight between 16,000–19,700 lbs and a wheelbase of 103 inches. The A-64 increases capacity to around 125 hp with additional hydraulic strength and weight, making it ideal for mid-range loader applications. The A-66, the largest in the lineup, is powered by a 6.6L 6-cylinder diesel rated at 160 hp, with operating weights up to 29,000 lbs and a wheelbase of 111 inches, offering maximum lift and breakout capacity for heavy-duty loading and material handling tasks.
The workshop repair manual provides full service coverage for these models across two volumes. Major sections include the engine system, fuel and electrical systems, transmission, axles, brakes, and drive shafts, along with wheels and tires. Additional coverage includes steering, hydraulics, loader frame and linkage, operator’s platform and sheet metal, as well as heating and air conditioning systems. It also provides detailed procedures for engine-transmission removal, component overhauls, and reference information. Step-by-step troubleshooting, lubrication guides, wiring diagrams, and hydraulic schematics ensure accurate diagnostics and efficient servicing.
Key Highlights
- Ford A-62: ~103 hp, 16,000–19,700 lbs operating weight, 103 in wheelbase
- Ford A-64: ~125 hp, mid-range capacity with enhanced hydraulics
- Ford A-66: ~160 hp, 23,900–29,000 lbs operating weight, 111 in wheelbase
- Hydraulic capacities up to 76 GPM total flow at 2500 psi system pressure
- Workshop manual sections: engine, fuel, electrical, transmission, axles, brakes, steering, hydraulics, loader frames, and operator systems
- Includes lubrication charts, wiring diagrams, and hydraulic schematics
- Engine and transmission removal and component overhaul procedures included
- Designed to maintain factory performance, maximize uptime, and ensure long-term durability
Table of Content
📙 Table of Contents
Vol. 1
- Vol. 1
Table Of Contents
- Table of Contents
Engine System
- Engine System
Fuel System
- Fuel System
Electrical System
- Electrical System
Transmission
- Transmission
Engine – Transmission Removal
- Engine – Transmission Removal
Axles, Brakes, Drive Shafts, Wheels And Tires
- Axles, Brakes, Drive Shafts, Wheels and Tires
Vol. 2
- Vol. 2
- Table of Contents
- Steering
- Hydraulic System
- Ford Wheel Loader Frames Loader Linkage and Buckets
- Operator’s Platform and Sheet Metal
- Air Conditioning and Heating
- Reference Information
Specification
| Specification | Ford A-62 | Ford A-64 | Ford A-66 |
|---|---|---|---|
| Years Produced | 1975 – 1983 | 1975 – 1983 | 1975 – 1983 |
| Engine Make / Size | Ford 4.4 L 4-cylinder diesel | Same series; larger power output version (≈ 125 hp gross) similar to A-66 family | Ford 6.6 L 6-cylinder diesel |
| Gross Power | ≈ 103 hp (76.8 kW) :contentReference[oaicite:0]{index=0} | ≈ 125 hp (≈93 kW) :contentReference[oaicite:1]{index=1} | ≈ 160 hp (119.3 kW) :contentReference[oaicite:2]{index=2} |
| Net Power | ≈ 100 hp (74.6 kW) :contentReference[oaicite:3]{index=3} | Not clearly listed | ≈ 150 hp (111.9 kW) :contentReference[oaicite:4]{index=4} |
| Fuel Tank Capacity | ≈ 40 gal (151.4 L) :contentReference[oaicite:5]{index=5} | Same, likely ≈ 40-50 gal depending on variant | ≈ 50 gal (≈ 189.2 L) :contentReference[oaicite:6]{index=6} |
| Hydraulic System (Open Center) / Hydraulic Oil Capacity | ≈ 40 gal (151.4 L) :contentReference[oaicite:7]{index=7} | ≈ similar to A-66 / A-62 series | ≈ 50 gal (189.2 L) :contentReference[oaicite:8]{index=8} |
| System Pressure / Main Pump Flow | ≈ 2500 psi; main flow ~17 gpm; total flow ~47 gpm; steering ~13 gpm :contentReference[oaicite:9]{index=9} | Likely ~ same pressure; flows somewhat higher (not confirmed) | ≈ 2500 psi; pump flow ~32 gpm; total flow ~76 gpm; steering ~22 gpm :contentReference[oaicite:10]{index=10} |
| Wheelbase | 103 in (261 cm) :contentReference[oaicite:11]{index=11} | Same as A-66 family (~111 in or slightly less) depending on configuration | 111 in (281 cm) :contentReference[oaicite:12]{index=12} |
| Weight (Operating / Loaded) | 16,114 – 19,740 lbs (≈ 7,305-8,952 kg) depending on bucket and options :contentReference[oaicite:13]{index=13} | ≈ between A-62 and A-66, likely ~18,000-22,000 lbs depending on build (not confirmed) | 23,932 – 29,054 lbs (≈ 10,855-13,180 kg) depending on bucket, tires, etc. :contentReference[oaicite:14]{index=14} |
| Tires (Front / Rear) | 15.5-25 front; 15.5-25 rear :contentReference[oaicite:15]{index=15} | Likely same tire size family; slight variations with heavier option tyres | 20.5-25 front; 20.5-25 rear :contentReference[oaicite:16]{index=16} |
