Ford 8700 and 9700 Tractor Repair Manual
$32.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Tractor |
| Model | 8700 and 9700 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 40870020 |
| Language | English |
| Format | |
| No of Pages | 484 |
The Ford 8700 and 9700 tractors are part of Ford’s powerful late 1970s row-crop lineup, engineered to deliver strength, durability, and efficiency for heavy farming tasks. Both tractors are equipped with Ford’s proven 401 cubic inch (6.6L) 6-cylinder diesel engine, with the 8700 producing around 127 gross horsepower and the 9700 stepping up to approximately 146 gross horsepower. Designed for row-crop operations, these tractors combine high PTO and drawbar outputs, dependable drivetrains, and robust hydraulics, making them reliable workhorses in the field.
The Ford 8700 delivers roughly 110 PTO horsepower and about 100 drawbar horsepower, while the Ford 9700 increases output to around 125–130 PTO horsepower and 115 drawbar horsepower. Transmission choices include an 8-speed gear drive or an optional 16-speed Dual Power system, providing more flexibility under load. Hydraulics are open-center systems with pump flows of ~15.5 gpm and steering flow of 4.2 gpm, operating at approximately 2,500 psi. Both tractors feature independent 540/1000 rpm PTOs, Category II three-point hitches with lift capacities of ~5,764 lbs at 24 inches, and fuel capacities of 58 gallons for long working hours. With operating weights between 9,800 and 12,800 lbs and wheelbases around 110–118 inches, these tractors balance stability and traction for demanding field operations.
The Ford 8700 and 9700 Tractor Repair Manual provides complete factory service guidance. Major sections include engine system, fuel system, electrical system, transmission and clutch, rear axle, brakes and PTO, hydraulic system, steering system, front axle, wheels and tires, air conditioning and heating, and component removal. Each section contains step-by-step procedures, exploded diagrams, troubleshooting charts, lubrication and maintenance schedules, torque specifications, and wiring and hydraulic schematics. This manual is an essential resource for technicians, restorers, and owners seeking accurate repairs and professional maintenance.
Key Highlights
- Ford 8700: ~127 gross hp, ~110 PTO hp, ~100 drawbar hp
- Ford 9700: ~146 gross hp, ~125–130 PTO hp, ~115 drawbar hp
- Transmission: 8-speed gear or 16-speed Dual Power
- Hydraulics: open-center, ~15.5 gpm pump flow, ~2,500 psi
- Rear hitch: Category II, ~5,764 lbs lift at 24 inches
- Independent PTO with 540/1000 rpm options
- Fuel capacity: ~58 gallons for extended operation
- Operating weight: 9,800–12,800 lbs; wheelbase: 110–118 inches
- Workshop manual sections: engine, fuel, electrical, transmission, PTO, hydraulics, rear axle/brakes, steering, A/C & heating, component removal
- Includes wiring and hydraulic diagrams, lubrication charts, torque specifications, and troubleshooting guides
Table of Content
📙 Table of Contents
Engine System
- Engine System
Fuel System
- Fuel System
Electrical System
- Electrical System
Transmission And Clutch
- Transmission and Clutch
Rear Axle, Brakes, And Power Take-Off
- Rear Axle, Brakes, and Power Take-Off
Hydraulic System
- Hydraulic System
Steering System, Front Axle, Wheels And Tires
- Steering System, Front Axle, Wheels and Tires
Air Conditioning And Heating
- Air Conditioning and Heating
Component Removal
- Component Removal
Specification
| Specification | Ford 8700 | Ford 9700 |
|---|---|---|
| Years Produced | 1977 – 1979 | 1977 – 1979 |
| Engine | Ford 6-cyl diesel, 401 cu in (6.6 L) | Ford 6-cyl diesel, 401 cu in (6.6 L) |
| Gross Power | ~127 hp | ~146 hp |
| PTO Power (Tested) | ~110 hp | ~125–130 hp |
| Drawbar Power (Tested) | ~100 hp | ~115 hp |
| Transmission | 8-speed gear or 16-speed Dual Power | 8-speed gear or 16-speed Dual Power |
| Hydraulics | Open center; pump ~15.5 gpm; steering 4.2 gpm | Open center; pump ~15.5 gpm; steering 4.2 gpm |
| Rear Hitch / Lift Capacity | Category II; ~5,764 lbs (2,614 kg) at 24 in | Category II; ~5,764 lbs (2,614 kg) at 24 in |
| PTO | Independent; 540/1000 rpm | Independent; 540/1000 rpm |
| Fuel Capacity | ~58 gal (220 L) | ~58 gal (220 L) |
| Weight | ~9,800 – 12,270 lbs | ~10,500 – 12,800 lbs |
| Wheelbase | ~110 in (2WD), ~118 in (4WD) | ~110 in (2WD), ~118 in (4WD) |
| Tires (Standard) | Front: 10.00-16; Rear: 18.4-38 | Front: 10.00-16; Rear: 18.4-38 |
| Brakes / Steering | Hydraulic wet disc; power steering | Hydraulic wet disc; power steering |
| Operator Station | Open station or optional cab with A/C | Open station or optional cab with A/C |
