Ford 7840, 8240, 8340 Tractor Repair Manual
$35.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Tractor |
| Model | 7840, 8240, 8340 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 40564061 |
| Language | English |
| Format | |
| No of Pages | 1452 |
The Ford 7840, 8240, and 8340 tractors are part of Ford’s PowerStar 40 Series, produced in the early to mid-1990s as high-performance row-crop and utility tractors. Designed for durability and versatility, they feature powerful Ford 6-cylinder diesel engines with horsepower ratings ranging from ~90 hp on the 7840 to over 106 hp on the 8340. Built for demanding agricultural operations, these tractors combine strong drivetrains, advanced hydraulics, and operator-focused cab options to deliver reliability and productivity in the field.
The 7840 provides around 90 hp at the PTO, the 8240 increases this to ~96–106 hp, and the 8340 tops the range with ~110 hp tested PTO power. Transmission options include 12-speed synchronized, 16-speed shuttle, and premium SLE power-shift variants, giving operators flexibility to match performance with task requirements. Hydraulics are available in open-center or closed-center load-sensing configurations, with flows from ~17.4 gpm to ~20 gpm and system pressures around 2,100 psi. Rear hitch lift capacities range from ~6,200 lbs to over 8,700 lbs depending on configuration, while fuel capacities of ~57 gallons ensure extended field operation. Wheelbases of ~103–106 inches and weights from ~8,000 to 10,900 lbs provide excellent stability and traction for heavy implements.
The comprehensive repair manual provides factory-level service coverage for the Ford 7840, 8240, and 8340 tractors. Major sections include engine system, fuel system, electrical systems, clutches, transmission systems, power take-off, rear axle and brakes, hydraulic systems, steering systems, front axle, cab, and tractor separation procedures. Each section contains detailed step-by-step repair procedures, exploded component diagrams, wiring and hydraulic schematics, torque specifications, lubrication data, and troubleshooting guides. This manual is essential for technicians and owners seeking to maintain, service, or restore these tractors to factory standards.
Key Highlights
- Ford 7840: ~90 PTO hp, tested drawbar ~75 hp
- Ford 8240: ~96–106 PTO hp depending on variant
- Ford 8340: ~106–110 PTO hp, premium model of the series
- Transmission options: 12-speed, 16-speed shuttle, and premium SLE power-shift
- Hydraulic flow: ~17.4–20 gpm; system pressure ~2,100 psi
- Rear hitch lift: ~6,200–8,700 lbs depending on configuration
- Fuel tank: ~57 gallons for extended operating time
- Operating weight: ~8,000–10,900 lbs; wheelbase: 103–106 inches
- Workshop manual sections: engine, fuel, electrical, clutch, transmission, PTO, hydraulics, axle/brakes, steering, cab, separation
- Includes wiring and hydraulic diagrams, torque specifications, lubrication charts, and troubleshooting guides
Table of Content
📙 Table of Contents
Health And Safety
- Health and Safety
Part 1 – Engine System
- Part 1 – Engine system
Part 2 – Fuel System
- Part 2 – Fuel System
Part 3 – Electrical Systems
- Part 3 – Electrical Systems
Part 4 – Clutches
- Part 4 – Clutches
Part 5 – Transmissions Systems
- Part 5 – Transmissions Systems
Part 6 – Power Take-Off
- Part 6 – Power Take-Off
Part 7 – Rear Axle And Brakes
- Part 7 – Rear Axle and Brakes
Part 8 – Hydraulic Systems
- Part 8 – Hydraulic Systems
Part 9 – Steering Systems
- Part 9 – Steering Systems
Part 10 – Front Axle
- Part 10 – Front Axle
Part 11 – Cab
- Part 11 – Cab
Part 12 – Separating Tractor
- Part 12 – Separating Tractor
Specification
| Specification | Ford 7840 | Ford 8240 | Ford 8340 |
|---|---|---|---|
| Years Produced | ~1992-1995 :contentReference[oaicite:0]{index=0} | ~1992-1995 :contentReference[oaicite:1]{index=1} | ~1992-1995 :contentReference[oaicite:2]{index=2} |
| PTO Claimed / Tested Power | Claimed PTO ~ 90 hp; Tested PTO ~ 90.4 hp; Drawbar ~ 75.2 hp :contentReference[oaicite:3]{index=3} | Claimed PTO ~ 96–106 hp; Tested similar; Drawbar somewhat lower :contentReference[oaicite:4]{index=4} | Claimed PTO ~ 106 hp; Tested PTO ~ 110.3 hp; Drawbar ~ 96.7 hp :contentReference[oaicite:5]{index=5} |
| Hydraulic System / Flow / Pressure | Open-center (S/SL) · Closed-center load sensing (SLE); pump flow ~ 17.4 gpm; ~ 20 gpm in SLE; steering pressure ~ 2100 psi :contentReference[oaicite:6]{index=6} | Same pump flow specs: ~ 17.4 gpm; optional SLE ~ 20 gpm; pressure ~ 2100 psi :contentReference[oaicite:7]{index=7} | Same style hydraulics: ~ 17.4 gpm SL; ~ 20 gpm SLE; steering pressure ~ 2100 psi :contentReference[oaicite:8]{index=8} |
| Rear Hitch / Lift Capacity at 24 in (610 mm) | ~ 6,210 lbs (SL) / ~ 8,240 lbs (optional) / ~ 8,710 lbs (SLE optional) depending on variant :contentReference[oaicite:9]{index=9} | Same lift ranges (≈ 6,210 lbs and optional ~8,240 lbs etc.) for SL / SLE variants :contentReference[oaicite:10]{index=10} | Also similar lift spec: ~ 6,210 lbs (SL) to ~ 8,710 lbs optional (SLE) depending on configuration :contentReference[oaicite:11]{index=11} |
| Drive / Transmission Options | 2WD (4×2) base; optional 4WD / MFWD; variants S, SL, SLE; transmissions include 8-speed, 12-speed synchronized, 16-speed / power shift in premium trims :contentReference[oaicite:12]{index=12} | Same variant options: SL, SLE; same drive configurations and transmission classes :contentReference[oaicite:13]{index=13} | SL and SLE trims; power-shift / premium transmission in SLE; drive choices included; similar to 8240 / 7840 family :contentReference[oaicite:14]{index=14} |
| Dimensions, Tires, Weight, Wheelbase | Wheelbase: 106 in (2WD) / 103 in (4WD); Weight: ~ 8,076 to ~ 10,274 lbs depending on trim; Tires front 10.00-16, rear 18.4-34 :contentReference[oaicite:15]{index=15} | Similar wheelbase & weights: ~ 8,684 to ~ 10,882 lbs; same tire sizes; same wheelbase dimensions :contentReference[oaicite:16]{index=16} | Similar dimensions: wheelbase ~ 106 in / 103 in (2WD/4WD), weights in similar range; tires same pattern; variant configs affect weight :contentReference[oaicite:17]{index=17} |
| Fuel Tank Capacity | ~ 57.5 gallons (≈ 217.6 L) :contentReference[oaicite:18]{index=18} | Same fuel capacity ~ 57.5 gal :contentReference[oaicite:19]{index=19} | Also ~ 57.5 gal :contentReference[oaicite:20]{index=20} |
