Ford 6000 Series Tractor Repair Manual

$28.00

🚜 Equipment
Brand	FORD
Type	Tractor
Model	6000
📄 Documents
Type	Repair Manual
Publication	40600010
Language	English
Format	PDF
No of Pages	336

The Ford 6000 Series tractors, including the Ford 6000 and later Commander 6000, were introduced in the early 1960s as Ford’s first 6-cylinder row-crop tractors. Designed for power and versatility, these tractors came equipped with a 4.0L 6-cylinder diesel or 3.7L gasoline engine, producing approximately 66 hp at the PTO and nearly 60 hp at the drawbar. With a 10-speed full powershift transmission, independent PTO, and closed-center hydraulic system, the Ford 6000 set a new standard for operator convenience and field efficiency during its production years.

Key performance features include a Type II three-point hitch, tested PTO output of 66.9 hp, drawbar power of 59.3 hp, and a robust “Power-Stor” hydraulic system operating at around 1,900 psi. Rear lift capacity and hydraulic flow were sufficient to handle heavy implements, while a 26-gallon fuel tank enabled long working days. With an operating weight of 6,500–7,400 lbs and a wheelbase of about 95 inches, the tractor balanced stability with maneuverability. Tires were typically 6.00×16 at the front and 13.6×38 at the rear, providing solid traction for row-crop operations.

The Ford 6000 Series Tractor Repair Manual provides comprehensive service coverage for this model. Sections include power plant, transmission, PTO, rear axle and brakes, steering system, front axle and wheels, tires, and hydraulic system. The manual contains detailed disassembly and reassembly procedures, exploded diagrams, lubrication and maintenance charts, torque specifications, wiring and hydraulic schematics, and troubleshooting guides. It is an essential resource for owners, restorers, and technicians maintaining or repairing these tractors to original factory standards.

Key Highlights

Powered by a 6-cylinder 4.0L diesel or 3.7L gasoline engine
Tested PTO output: ~66.9 hp; Drawbar power: ~59.3 hp
Equipped with 10-speed full powershift transmission
Closed-center “Power-Stor” hydraulic system (~1,900 psi)
Independent PTO with 540/1000 rpm options
Fuel tank capacity: ~26 gallons for extended operation
Operating weight: 6,500–7,400 lbs; Wheelbase: ~95 inches
Rear hitch: Category II three-point hitch for heavy implements
Workshop manual sections: engine, transmission, PTO, rear axle/brakes, steering, front axle, wheels, tires, hydraulics
Includes wiring and hydraulic diagrams, lubrication charts, torque data, and troubleshooting procedures

Table of Content

📙 Table of Contents

Part One – Power Plant

Part One – Power Plant

Part Two – Transmission, Power Take-Off, Rear Axle And Brakes

Part Two – Transmission, Power Take-Off, Rear Axle and Brakes

Part Three – Steering, Front Axle, Wheels, And Tires

Part Three – Steering, Front Axle, Wheels, and Tires

Part Four – Hydraulic System

Part Four – Hydraulic System

Specification

Specification	Ford 6000
Years Produced	1961 – 1964 (Row-Crop), later as “Commander 6000” until ~1967 :contentReference[oaicite:0]{index=0}
Engine / Displacement	6-cylinder: ~4.0 L diesel or ~3.7 L gasoline :contentReference[oaicite:1]{index=1}
PTO / Claimed PTO Power	≈ 66.9 hp (tested) at PTO :contentReference[oaicite:2]{index=2}
Drawbar Power	≈ 59.3 hp (tested) :contentReference[oaicite:3]{index=3}
Transmission	10-speed full power shift (powershift) :contentReference[oaicite:4]{index=4}
Fuel Tank Capacity	≈ 26 gallons (98.4 L) :contentReference[oaicite:5]{index=5}
Hydraulic System Type & Capacity / Flow / Pressure	Closed-center “Power-Stor” hydraulics; ~3.5 gallons (13.2 L); pressure ~1,900 psi; pump flow ~4.5 gpm :contentReference[oaicite:6]{index=6}
Rear Axle / Hitch Type	Rear Type II three-point hitch; independent rear PTO; 540/1000 rpm PTO option :contentReference[oaicite:7]{index=7}
Weight / Operating Weight	≈ 6,500 to 7,405 lbs depending on variant :contentReference[oaicite:8]{index=8}
Wheelbase & Tires	Wheelbase ~ 95 in (~241 cm); Front tires 6.00×16; Rear tires 13.6×38 :contentReference[oaicite:9]{index=9}
Chassis / Drive / Brakes	2WD; power assist steering; differential with hydraulic wet-disc brakes; open operator station :contentReference[oaicite:10]{index=10}
