Ford 345C, 445C, 545C Backhoe Tractor Loader Repair Manual
$33.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Backhoe Loader Tractor |
| Model | 345C, 445C, 545C |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 40034530 |
| Language | English |
| Format | |
| No of Pages | 372 |
The Ford 345C, 445C, and 545C Backhoe Tractor Loaders are versatile industrial machines designed for construction, agricultural, and utility applications. Built with durable Ford diesel engines and heavy-duty drivetrains, these tractors combine tractor loader functionality with the power and hydraulics needed to support backhoe operations. Each model is engineered for performance, reliability, and ease of maintenance, with variations in horsepower, operating weight, and hydraulic capacity to match specific job requirements.
The Ford 345C is equipped with a 52 hp diesel engine and features transmission options including a 6-speed manual reversing or torque converter type, making it suitable for light-to-medium duty loading and excavation. The Ford 445C, also in the 52 hp class, provides enhanced loader functionality and is designed as a general-purpose tractor loader for farms and municipal work. The larger Ford 545C delivers approximately 62 hp, increased hydraulic output, and heavier operating weight (around 8,600–8,800 lbs), giving it greater capacity for construction and industrial operations. Across the range, operators benefit from independent PTO options, rear hitch configurations, and strong hydraulic loader pumps, ensuring versatility for attachments and implements.
The repair manual provides complete service coverage for these models, with detailed sections on the engine, fuel, electrical, clutch, transmission, PTO, rear axle and brakes, steering and front axle, loader hydraulics, and general hydraulic systems. It includes step-by-step disassembly and reassembly instructions, wiring diagrams, hydraulic schematics, torque specifications, lubrication guides, and troubleshooting procedures. The manual also covers tractor separation and reassembly, ensuring accurate servicing of major structural components.
Key Highlights
- Ford 345C: ~52 hp, ~8,740 lbs operating weight, 6-speed manual or torque converter transmission
- Ford 445C: ~52 hp, ~8,830 lbs operating weight, versatile loader/backhoe functions for municipal and farm work
- Ford 545C: ~62 hp, ~8,600–8,800 lbs operating weight, stronger hydraulics and industrial-grade performance
- Rear independent PTO (540 type) and hitch compatibility
- Loader pump capacity ~26 gallons with strong hydraulic lift performance
- Heavy-duty rear axle, brakes, and steering/front axle assemblies for durability
- Zeroing in on service efficiency with clear hydraulic and electrical schematics
- Workshop manual covers: engine, fuel, clutch, transmission, PTO, rear axle/brakes, loader and tractor hydraulics
- Step-by-step separation and reassembly procedures for major components
- Designed for long-term industrial reliability and ease of maintenance
Table of Content
📙 Table of Contents
Part 1 Engine Systems
- Part 1 Engine Systems
Part 2 Fuel Systems
- Part 2 Fuel Systems
Part 3 Electrical Systems
- Part 3 Electrical Systems
Part 4 Clutch
- Part 4 Clutch
Part 5 Transmission
- Part 5 Transmission
Part 6 Power Take-Off
- Part 6 Power Take-Off
Part 7 Rear Axle And Brakes
- Part 7 Rear Axle and Brakes
Part 8 Steering And Front Axle
- Part 8 Steering and Front Axle
Part 9 Loader Hydraulic System
- Part 9 Loader Hydraulic System
Part 10 Hydraulic Systems
- Part 10 Hydraulic systems
Part 11 Separating The Tractor
- Part 11 Separating the Tractor
Specification
| Specification | Ford 345C | Ford 445C | Ford 545C |
|---|---|---|---|
| Engine Power (Net) | ≈ 52 hp :contentReference[oaicite:0]{index=0} | ≈ 52 hp (same series) :contentReference[oaicite:1]{index=1} | ≈ 62 hp :contentReference[oaicite:2]{index=2} |
| Transmission Options | 6-speed manual reversing; optional torque converter types :contentReference[oaicite:3]{index=3} | Likely same options as 345C (6-speed manual, torque converter) :contentReference[oaicite:4]{index=4} | 6-speed manual reversing; 4- or 8-speed torque converter transmission options :contentReference[oaicite:5]{index=5} |
| Operating Weight (Loader / Tractor Loader with Loader) | ≈ 8,740 lbs (~3,965 kg) :contentReference[oaicite:6]{index=6} | ≈ 8,830 lbs (~4,005 kg) :contentReference[oaicite:7]{index=7} | ≈ 8,610–8,830 lbs (~3,905–4,005 kg), depending on 2WD or 4WD loader configuration :contentReference[oaicite:8]{index=8} |
| Wheelbase | — (data not clearly found) | — (data not clearly found) | ≈ 81 inches (~205 cm) wheelbase :contentReference[oaicite:9]{index=9} |
| Length (Loader / Total) | ≈ 14 ft 7 in (~4.45 m) :contentReference[oaicite:10]{index=10} | ≈ 15 ft 3 in (~4.65 m) :contentReference[oaicite:11]{index=11} | ≈ 15 ft 3 in (~4.65 m) :contentReference[oaicite:12]{index=12} |
| Width (without Loader Bucket) | ≈ 6 ft 9 in (~2.06 m) :contentReference[oaicite:13]{index=13} | ≈ 6 ft 9 in (~2.06 m) :contentReference[oaicite:14]{index=14} | ≈ 6 ft 9 in (~2.06 m) :contentReference[oaicite:15]{index=15} |
| Height (ROPS Cab / Top of Cab) | ≈ 7 ft 10 in (~2.39 m) :contentReference[oaicite:16]{index=16} | ≈ 7 ft 10 in (~2.39 m) :contentReference[oaicite:17]{index=17} | ≈ 7 ft 10 in (~2.39 m) :contentReference[oaicite:18]{index=18} |
| Fuel Capacity | — (data not clearly found) | — (data not clearly found) | ≈ 16 gal (~60.6 L) :contentReference[oaicite:19]{index=19} |
| Hydraulic System / Loader Pump Capacity | Loader pump approx 26 gal (~98.4 L) capacity :contentReference[oaicite:20]{index=20} | Likely similar to 345C (≈ 26 gal) :contentReference[oaicite:21]{index=21} | Loader pump ≈ 26 gal (~98.4 L) system; steering & hitch hydraulics also specified :contentReference[oaicite:22]{index=22} |
| PTO / Rear Hitch Features | Rear independent PTO, Type 540 :contentReference[oaicite:23]{index=23} | Same PTO & hitch style (industrial / backhoe loader style) :contentReference[oaicite:24]{index=24} | Rear independent PTO, Type 540; hitch rear Type I, draft sensing lift :contentReference[oaicite:25]{index=25} |
