Ford 340 Compact Loader Repair Manual
$19.00
| 🚜 Equipment | |
|---|---|
| Brand | FORD |
| Type | Compact Loader |
| Model | 340 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 40034010 |
| Language | English |
| Format | |
| No of Pages | 36 |
The Ford 340 Compact Loader is a versatile industrial tractor-loader designed for construction, utility, and agricultural applications. Manufactured between 1979 and 1984, the 340 series is powered by a Ford 2.9L 3-cylinder engine available in both gasoline and diesel configurations, producing approximately 47.5 hp gross power. Built on a durable industrial chassis with a wheelbase of 81.8 inches, power steering, and wet disc brakes, the Ford 340 combines strength, reliability, and ease of operation. With a hydraulic flow of 5.6 gpm and a lift capacity of about 1,940 lbs at 24 inches, it is engineered to handle demanding loader tasks with efficiency.
The Ford 340 Compact Loader features a 6-speed gear transmission (with optional 8-speed) and open-center hydraulics operating at 2,500 psi, supported by a 16-gallon fuel tank and hydraulic reservoir capacity of up to 12 gallons (with independent PTO). Standard tire sizes include 6.50×16 fronts and 13.6×28 rears, providing stability and traction in varied ground conditions. Its 12-volt electrical system with alternator charging ensures dependable starts and electrical support for attachments. These specifications make the 340 Compact Loader an efficient choice for heavy-duty loader operations while retaining compact versatility for jobsite maneuverability.
The comprehensive repair manual provides full service coverage for the Ford 340 Compact Loader. Major sections include description and operation, troubleshooting, pressure checks and adjustments, components overhaul, control valves, hydraulic motors, cylinders, lubrication and maintenance, periodic service inspections, electrical systems, and complete technical specifications. Step-by-step service procedures, hydraulic and electrical schematics, torque charts, lubrication data, and troubleshooting guides are included to support accurate diagnosis and professional-grade repair. This manual equips operators and technicians with the knowledge to maintain peak performance and extend machine life.
Key Highlights
- Ford 2.9L 3-cylinder gasoline or diesel engine, ~47.5 hp gross power
- 6-speed gear drive (optional 8-speed), 2WD, power steering, wet disc brakes
- Hydraulic system: 5.6 gpm flow, 2,500 psi pressure, ~1,940 lbs lift at 24”
- Fuel tank: 16 gallons; Hydraulic system capacity up to 12 gallons with PTO
- Wheelbase: 81.8 inches; Tires: 6.50×16 (front), 13.6×28 (rear)
- 12-volt electrical system with alternator charging
- Workshop manual coverage: operation, troubleshooting, hydraulic systems, electrical, lubrication, service inspections
- Includes hydraulic/electrical schematics, lubrication charts, torque data, and step-by-step repair procedures
- Essential for maintaining factory-level reliability and extending machine life
Table of Content
📙 Table of Contents
Description And Operation
- Description and Operation
Troubleshooting
- Troubleshooting
Pressure Checks And Adjustments
- Pressure Checks and Adjustments
Components Overhaul
- Components Overhaul
Control Valves
- Control Valves
Hydraulic Motors
- Hydraulic Motors
Cylinders
- Cylinders
Lubrication And Maintenance
- Lubrication and Maintenance
Periodic Service Inspections
- Periodic Service Inspections
Electrical
- Electrical
Specifications
- Specifications
Specification
| Specification | Ford 340 Compact Loader / 340 Industrial Tractor w/ Loader |
|---|---|
| Years Produced | 1979 – 1981 (340); 1981-1984 (340A) :contentReference[oaicite:0]{index=0} |
| Engine / Displacement | Ford 2.9 L 3-cylinder (gasoline or diesel) :contentReference[oaicite:1]{index=1} |
| Gross Power | ≈ 47.5 hp gross / ≈ 44.5 hp net :contentReference[oaicite:2]{index=2} |
| Transmission | 6-speed unsynchronized gear; 8-speed option; 2WD; power steering; final drives planetary inboard :contentReference[oaicite:3]{index=3} |
| Hydraulic System Type | Open-center hydraulic system; loader pump optional with higher flow; independent PTO optional :contentReference[oaicite:4]{index=4} |
| Hydraulic Pump Flow / Pressure | ≈ 5.6 gpm (≈ 21.2 L/min) pump flow; ≈ 2,500 psi operating pressure :contentReference[oaicite:5]{index=5} |
| Fuel Tank Capacity | 16 gal (≈ 60.6 L) :contentReference[oaicite:6]{index=6} |
| Hydraulic Reservoir / System Capacity | ≈ 8.5 gal (≈ 32.2 L); with independent PTO up to ~12 gal (≈ 45.4 L) :contentReference[oaicite:7]{index=7} |
| Steering / Brakes | Power steering; mechanical wet-disc brakes; 2-WD :contentReference[oaicite:8]{index=8} |
| Rear Hitch / Lift Capacity | Rear Type I hitch; Rear lift at 24″ (610 mm) = ~1,940 lbs (≈ 879 kg) :contentReference[oaicite:9]{index=9} |
| PTO (Power Take-off) | Rear PTO optional; independent PTO optional; Rear PTO Type 540 rpm @ ~1,800 rpm engine :contentReference[oaicite:10]{index=10} |
| Wheelbase | ≈ 81.8 in (≈ 207 cm) :contentReference[oaicite:11]{index=11} |
| Tires (Front / Rear) | Front: 6.50×16; Rear: 13.6×28 :contentReference[oaicite:12]{index=12} |
| Electrical System | 12-volt system; alternator 32 A (gas); optional higher amp; Battery AH ~77 (gas) / ~128 (diesel) :contentReference[oaicite:13]{index=13} |
