DEUTZ Euro 2 Series 1000 Engine Repair Manual

HOW TO CONSULT THE MANUAL

Removal and Refitting of Assembled Units
(1) The sequence and methods for removing assembled units are detailed under the removal procedure. If the refitting process follows the exact reverse order of removal, it is not described again.
(2) Special techniques that apply only to refitting are indicated by a specific symbol. This same symbol is shown at the end of each major step in the removal procedure to highlight parts requiring special attention during refitting.

Example:

• REMOVAL OF UNIT: Operation heading

• Safety rules relevant to the procedure

• Individual step in the process

• Special technique or important note related to removal

• Indicates special instruction for refitting

• Recover fluid (oil, liquid, fuel) and note quantity

Refitting Example:

• REFITTING UNIT: Operation heading

• Refitting is the reverse of removal

• Technique specific to refitting

• Critical note or special technique for refitting

• Fill with oil or liquid and state quantity

List of Special Tools
(1) For details on the type, code numbers, and quantity of tools (e.g., T1, T2, etc.) required for procedures, refer to the SPECIAL TOOLS section.

Tightening Torques
(1) Within the procedures, a designated symbol indicates a specific torque value that must be applied as determined through testing.
(2) If the symbol is not shown, refer to the torque values listed in Section 00 of this manual.
