Case SR270, SV300, SV340, TR340, TV380 SkidSteer Repair Manual (Tier 4B)
$37.00
| 🚜 Equipment | |||
|---|---|---|---|
| Brand | CASE | ||
| Type | SkidSteer | ||
| Model | SR270, SV300, SV340, TR340, TV380 | ||
| 📄 Documents | |||
| Language | English | ||
| Format | |||
| Title | Serial | Publication No. | Pages |
| Repair Manual (Tier 4B Final) | SR270 / SV340 – SN NGM418237 and above; TR340 / TV380 SN NGM418237 and above; | 47916277 | 2492 |
| Repair Manual (Tier 4B Final) | SR270 – SN NFM481941 and above; SV300 – NFM470295 and above; TR340 – SN NFM482972 and above; TV380 – SN NFM483044 and above; | 47685161 | 2844 |
| Repair Manual (Tier 4B Final) | SR 270 / SV 340 – SN NHM435463 and above; TR340 / TV380 – SN NHM435463 and above | 48060319 | 2330 |
- Description
- Additional information
- Table of Content
- Specification
- Buyer Questions & Answers
- Reviews (0)
The Case SR270, SV300, SV340, TR340, and TV380 Tier 4B Skid Steer and Compact Track Loaders are high-performance machines engineered for maximum productivity, lifting power, and reliability in demanding construction, agricultural, and material-handling environments. Equipped with 90 gross horsepower (84 net hp) FPT turbocharged diesel engines delivering 282 lb·ft of torque, these loaders combine advanced Tier 4 Final SCR technology with the durability and efficiency expected from Case equipment.
The SR270 provides a 2,700 lb rated operating capacity with radial lift design, ideal for grading and digging tasks. The SV300 offers 3,000 lb rated capacity, while the SV340 increases this to 3,400 lb, both featuring vertical lift for improved reach and truck loading efficiency. For enhanced traction and flotation, the TR340 and TV380 track loaders deliver rated capacities of 3,400 lb and 3,800 lb respectively, with operating weights over 10,000 lb for superior stability. Hydraulic performance includes a standard 24.2 GPM system with an optional high-flow of 37.6 GPM at 3,450 psi, enabling efficient operation of demanding attachments. Breakout forces up to 8,700 lb ensure strong digging and lifting power across the range.
The service manual provides full coverage of all systems including engine, power coupling, hydrostatic drive, axles, brakes and controls, hydraulic systems, electrical systems, frames, ballasting, tracks and suspension, wheels, loader and bucket assemblies, and operator cab and bodywork. Detailed electrical and hydraulic schematics, both for electro-hydraulic and mechanical controls, are included along with torque specifications, lubrication guides, and troubleshooting procedures, ensuring professional maintenance and long service life.
Key Highlights
- Tier 4 Final 90 hp turbocharged diesel engine delivering 84 net hp and 282 lb·ft torque
- Rated operating capacities: SR270 – 2,700 lb; SV300 – 3,000 lb; SV340 – 3,400 lb; TR340 – 3,400 lb; TV380 – 3,800 lb
- Radial lift (SR270, TR340) and vertical lift (SV300, SV340, TV380) configurations
- Hydraulic system: 24.2 GPM standard, 37.6 GPM high-flow @ 3,450 psi
- Breakout force up to 8,700 lb for tough digging and lifting operations
- Operating weights: SR270 ~8,117 lb; SV300 ~8,655 lb; SV340 ~9,100 lb; TR340 ~10,000 lb; TV380 ~10,550 lb
- Comprehensive manual coverage: engine, hydraulics, hydrostatic drive, axles, brakes, tracks, loader, and electrical systems
- Includes electro-hydraulic and mechanical control schematics for accurate diagnostics
- Designed with operator comfort and serviceability in mind, featuring climate control cab options and ergonomic controls
| Publication | 47916277, 47685161, 48060319 |
|---|
Table of Content
📙 Table of Contents – Publication Number 48060319
Contents
- Contents
Introduction
- INTRODUCTION
Engine – 10
- Engine – 10
Power Coupling – 19
- Power coupling – 19
Front Axle System – 25
- Front axle system – 25
Rear Axle System – 27
- Rear axle system – 27
Hydrostatic Drive – 29
- Hydrostatic drive – 29
Brakes And Controls – 33
- Brakes and controls – 33
Hydraulic Systems – 35
- Hydraulic systems – 35
Frames And Ballasting – 39
- Frames and ballasting – 39
Wheels – 44
- Wheels – 44
Tracks And Track Suspension – 48
- Tracks and track suspension – 48
Cab Climate Control – 50
- Cab climate control – 50
Electrical Systems – 55
- Electrical systems – 55
Front Loader And Bucket – 82
- Front loader and bucket – 82
Platform, Cab, Bodywork, And Decals – 90
- Platform, cab, bodywork, and decals – 90
Special Tool Index
- SPECIAL TOOL INDEX
Electrical Schematic Electro-Hydraulic (Eh) Controls-48049039
- ELECTRICAL SCHEMATIC ELECTRO-HYDRAULIC (EH) CONTROLS-48049039
Electrical Schematic Mechanical Controls-48090746
- ELECTRICAL SCHEMATIC MECHANICAL CONTROLS-48090746
Hydraulic Schematic-51423450
- HYDRAULIC SCHEMATIC-51423450
Specification
| Specification | Case SR270 | Case SV300 | Case SV340 | Case TR340 | Case TV380 |
|---|---|---|---|---|---|
| Engine Model & Type | FPT F5B FL413B, 4-cyl turbo diesel, Tier 4 Final SCR | FPT F5B FL413B, 4-cyl turbo diesel, Tier 4 Final SCR | FPT F5B FL413B, 4-cyl turbo diesel, Tier 4 Final SCR | FPT F5B FL413B, 4-cyl turbo diesel, Tier 4 Final SCR | FPT F5B FL413B, 4-cyl turbo diesel, Tier 4 Final SCR |
| Gross / Net Horsepower | 90 hp gross / 84 hp net | 90 hp gross / 84 hp net | 90 hp gross / 84 hp net | 90 hp gross / 84 hp net | 90 hp gross / 84 hp net |
| Peak Torque | 282 lb·ft | 282 lb·ft | 282 lb·ft | 282 lb·ft | 282 lb·ft |
| Rated Operating Capacity | 2,700 lb (1,225 kg) | 3,000 lb (1,361 kg) | 3,400 lb (1,543 kg) | 3,400 lb (1,543 kg) | 3,800 lb (1,724 kg) |
| Tipping Load | 5,400 lb | 6,000 lb | 6,800 lb | 6,800 lb | 7,600 lb |
| Hydraulic Auxiliary Flow | 24.2 gpm (std) / 37.6 gpm (high flow) | 24.2 gpm (std) / 37.6 gpm (high flow) | 24.2 gpm (std) / 37.6 gpm (high flow) | 24.2 gpm (std) / 37.6 gpm (high flow) | 24.2 gpm (std) / 37.6 gpm (high flow) |
| Breakout Force (Bucket) | ~8,500 lb | ~8,700 lb | ~8,700 lb | ~8,700 lb | ~8,700 lb |
| Operating Weight | 8,117 lb (3,682 kg) | 8,655 lb (3,925 kg) | 9,100 lb (4,128 kg) | 10,000 lb (4,536 kg) | 10,550 lb (4,785 kg) |
| Lifting Geometry | Radial | Vertical | Vertical | Radial (Track Loader) | Vertical (Track Loader) |
