Case SR175, SV185 SkidSteer Repair Manual
$35.00
| 🚜 Equipment | |||
|---|---|---|---|
| Brand | CASE | ||
| Type | SkidSteer | ||
| Model | SR175, SV185 | ||
| 📄 Documents | |||
| Language | English | ||
| Format | |||
| Title | Tier /Serial | Publication No. | Pages |
| Repair Manual | Tier 4B (final) – SN NDM465633 and above; SN NDM466611 and above | 47711658 | 1573 |
| Repair Manual | Tier 4B (final) – SN NEM465956 and above; SN NEM466759 and above | 47851947 | 1670 |
- Description
- Additional information
- Table of Content
- Specification
- Buyer Questions & Answers
- Reviews (0)
The Case SR175 and SV185 Skid Steer Loaders are versatile, mid-frame machines built for performance, comfort, and durability in construction, agriculture, and material-handling applications. Designed as part of Case’s Alpha Series, these loaders combine efficient Tier 4 Final turbocharged diesel engines with strong lift capacities and responsive hydraulics, making them suitable for demanding job site conditions.
The Case SR175 is equipped with a 67 hp gross (64 net) ISM N844LTA-DI-F-50 engine, delivering a rated operating capacity of 1,750 lbs. The SV185 uses a 60 hp gross (57 net) ISM N844LTA-DI-F-45 engine, increasing the rated load to 1,850 lbs. Both machines feature DOC-only Tier 4 Final solutions, simplifying emissions compliance without adding DEF or complex systems. Hydraulic performance includes 20.6 GPM (SR175) and up to 24.2 GPM (SV185) at ~3,050 psi, supporting powerful breakout forces and efficient attachment operation. Travel speeds range from 7.0 to 7.4 mph, with optional high-flow on the SV185 providing even greater productivity.
The service manual provides complete system coverage, including the engine, hydrostatic drive, front and rear axle systems, brakes and controls, hydraulic systems, electrical systems, loader and bucket assemblies, wheels, cab climate control, and frame and ballasting. Detailed service instructions, wiring and hydraulic schematics, torque specifications, lubrication guides, and troubleshooting procedures ensure professional maintenance and repair, keeping these machines at peak performance.
Key Highlights
- Case SR175: 67 hp gross (64 net) turbocharged diesel, 1,750 lb rated operating capacity
- Case SV185: 60 hp gross (57 net) turbocharged diesel, 1,850 lb rated operating capacity
- Hydraulic performance: 20.6 GPM @ 3,050 psi (SR175) / 24.2 GPM high-flow option (SV185)
- Operating weights: ~6,200 lbs (SR175) / ~6,500 lbs (SV185)
- Travel speed: 7.0–7.4 mph with smooth hydrostatic drive
- DOC-only Tier 4 Final emissions compliance (no DEF required)
- Manual covers engine, hydrostatic drive, hydraulics, axles, brakes, and electrical systems
- Includes wiring diagrams, hydraulic schematics, torque values, and lubrication schedules
- Engineered for operator comfort with cab climate control and ergonomic platform design
| Publication | 47711658, 47851947 |
|---|
