Case SR130, SR160 SkidSteer Service Manual
$36.00
| 🚜 Equipment | |||
|---|---|---|---|
| Brand | CASE | ||
| Type | SkidSteer | ||
| Model | SR130, SR160 | ||
| 📄 Documents | |||
| Language | English | ||
| Format | |||
| Title | Tier /Serial | Publication No. | Pages |
| Repair Manual | Tier 3 and Tier 4B (final) – SN NEM464869 and above; SN NDM477801 and above | 47711585 | 2529 |
| Repair Manual | Tier 4B (final) – SN NDM442151 and above; SN NDM477801 and above | 47712039 | 1523 |
- Description
- Additional information
- Table of Content
- Specification
- Buyer Questions & Answers
- Reviews (0)
The Case SR130 and SR160 Skid Steer Loaders are part of the SR Series, engineered to deliver dependable performance, operator comfort, and ease of service in compact, versatile designs. With rated operating capacities of 1,300 lbs for the SR130 and 1,600 lbs for the SR160, these loaders are ideal for construction, agriculture, landscaping, and material handling applications where maneuverability and productivity are key.
The Case SR130 is powered by a 49 hp ISM N844T/M3 diesel engine, while the SR160 steps up to a turbocharged ISM N844LT-F engine producing 60 gross hp (57 net). Both models are Tier 4 Final compliant, offering reliable performance with improved fuel efficiency. Hydraulic systems deliver 17.5 GPM on the SR130 and 18.4 GPM on the SR160, providing strong power for a wide range of attachments. Travel speeds of up to 7.4 mph ensure efficient cycle times on busy job sites. Operating weights range from 5,000 lbs (SR130) to 5,510 lbs (SR160), giving the machines excellent stability without sacrificing compact maneuverability.
The service manual provides full coverage of critical systems, including engine, hydrostatic drive, front and rear axle systems, brakes and controls, hydraulics, electrical systems, frames and ballasting, wheels, cab climate control, loader and bucket, and operator platform details. Step-by-step service procedures, hydraulic and electrical schematics, torque specifications, lubrication charts, and troubleshooting guides are included to support accurate maintenance and professional repairs.
Key Highlights
- SR130: 49 hp ISM diesel engine, 1,300 lb rated operating capacity, ~5,000 lb operating weight
- SR160: 60 hp turbocharged diesel engine, 1,600 lb rated capacity, ~5,510 lb operating weight
- Hydraulic flow: 17.5 GPM (SR130) / 18.4 GPM (SR160) for efficient attachment operation
- Travel speeds up to 7.4 mph for quick cycle times
- Compact dimensions allow excellent maneuverability on tight job sites
- Service manual covers engine, hydrostatic drive, hydraulics, axles, brakes, and electrical systems
- Includes schematics, torque values, lubrication schedules, and troubleshooting procedures
- Designed for operator comfort with cab climate control and ergonomic controls
- Robust build ensures durability and long service life in demanding conditions
| Publication | 47711585, 47712039 |
|---|
Table of Content
📙 Table of Contents – Publication Number 47711585
Contents
- Contents
Introduction
- INTRODUCTION
Engine – 10
- Engine – 10
Front Axle System – 25
- Front axle system – 25
Rear Axle System – 27
- Rear axle system – 27
Hydrostatic Drive – 29
- Hydrostatic drive – 29
Brakes And Controls – 33
- Brakes and controls – 33
Hydraulic Systems – 35
- Hydraulic systems – 35
Frames And Ballasting – 39
- Frames and ballasting – 39
Wheels – 44
- Wheels – 44
Cab Climate Control – 50
- Cab climate control – 50
Electrical Systems – 55
- Electrical systems – 55
Front Loader And Bucket – 82
- Front loader and bucket – 82
Platform, Cab, Bodywork, And Decals – 90
- Platform, cab, bodywork, and decals – 90
Special Tool Index
- SPECIAL TOOL INDEX
Specification
| Specification | Case SR130 Skid-Steer Loader | Case SR160 Skid-Steer Loader |
|---|---|---|
| Engine Model & Type | ISM N844T/M3, Tier 4 Final | ISM N844LT-F, Turbocharged Tier 4 Final |
| Gross / Net Power | ~49 hp (36 kW) | 60 hp gross / 57 hp net |
| Rated Operating Capacity | 1,300 lb (≈590 kg) | 1,600 lb (≈725 kg) |
| Operating Weight | ~5,000 lb (2,268 kg) | ~5,510 lb (2.51 t) |
| Hydraulic Flow (Aux) | 17.5 gpm (66 L/min) | 18.4 gpm (70 L/min) |
| Travel Speed | 7 mph (11 kph) | 7.4 mph (11.9 kph) |
| Dimensions (L × W × H) | L: 10 ft 5 in · W: 4 ft 11 in · H: 6 ft 4 in | L: ~10 ft 5 in · W: ~5 ft · H: ~6 ft 4 in |
