CASE 85XT, 90XT, 95XT Skidsteer Repair Manual
$36.00
| đźšś Equipment | |
|---|---|
| Brand | CASE |
| Type | Skidsteer |
| Model | 85XT, 90XT, 95XT |
| đź“„ Documents | |
| Type | Repair Manual |
| Publication | 7-52254 |
| Language | English |
| Format | |
| No of Pages | 1436 |
The Case 85XT, 90XT, and 95XT Skid Steer Loaders are part of Case’s heavy-duty XT series, built for operators who require higher power, increased lift capacity, and exceptional durability in construction, landscaping, and agricultural applications. With engines ranging from 80 to 85 gross horsepower and net ratings of up to 74 hp, these loaders combine strength with fuel efficiency to handle demanding tasks with ease.
The 85XT is powered by a naturally aspirated 4-390 diesel engine, while the 90XT and 95XT feature turbocharged 4T-390 diesels, delivering extra torque and responsiveness. With rated operating capacities spanning from 2,400 to 3,150 lbs and tipping loads over 6,000 lbs, these machines are engineered for robust performance in material handling, grading, and attachment-heavy work. Hydraulic flow capacities of up to 28 GPM with relief pressures around 3,000 psi provide ample power for a wide range of tools and attachments, increasing job site productivity.
The repair manual covers every critical system in depth, including engines, fuel, electrical, power train, brakes, hydraulics, and mounted equipment. Foldout hydraulic and electrical schematics provide advanced troubleshooting capability, while detailed repair instructions, torque values, lubrication schedules, and service procedures ensure owners and technicians can maintain peak machine performance and long service life.
Key Highlights
- Case 4-cylinder diesel engines: 85XT (80 hp NA), 90XT & 95XT (85 hp turbocharged)
- Rated operating capacity: 85XT ~2,400 lbs, 90XT ~2,450 lbs, 95XT ~3,150 lbs
- Hydraulic systems up to 28 GPM at ~3,000 psi for attachment versatility
- Operating weights: 85XT ~8,057 lbs, 90XT ~8,950 lbs, 95XT ~9,050 lbs
- Comprehensive coverage of engine, power train, brakes, hydraulics, and mounted equipment
- Includes hydraulic and electrical schematic foldouts for professional troubleshooting
- Compact design with travel speeds up to 11 mph for efficient job site mobility
- Designed for long service life with straightforward maintenance access
Table of Content
đź“™ Table of Contents
Table Of Contents
- Table of Contents
General
- General
Engines
- Engines
Fuel System
- Fuel System
Electrical
- Electrical
Power Train
- Power Train
Brakes
- Brakes
Hydraulics
- Hydraulics
Mounted Equipment
- Mounted Equipment
Hydraulic And Electrical Schematic Foldout
- Hydraulic and Electrical Schematic Foldout
Specification
| Specification | Case 85XT Skid-Steer Loader | Case 90XT Skid-Steer Loader | Case 95XT Skid-Steer Loader |
|---|---|---|---|
| Years Produced | 1998 – 2005 | 1998 – 2005 | 1998 – 2005 |
| Model Type | Skid-Steer Loader | Skid-Steer Loader | Skid-Steer Loader |
| Engine Manufacturer | Case | Case | Case |
| Engine Model & Type | 4-stroke 4-cyl naturally aspirated 4-390 diesel | 4-stroke 4-cyl turbocharged 4T-390 diesel | 4-stroke 4-cyl turbocharged 4T-390 diesel |
| Displacement | 239 cu in (3.9 L) | 239 cu in (3.9 L) | 239 cu in (3.9 L) |
| Gross Power | 80 hp | 85 hp | 85 hp |
| Net Power | 69 hp | 74 hp | 74 hp |
| Rated Operating Capacity / Operating Load | ~2,400 lb | ~2,450 lb | ~3,150 lb |
| Operational Weight | 8,057 lb | 8,950 lb | 9,050 lb |
| Hydraulic Flow Capacity | 25 gpm | 25 gpm | ~28 gpm |
| Relief Valve Pressure | ~3,002 psi | ~3,002 psi | ~3,002 psi |
| Fuel Capacity | ~17 gal | ~20–21 gal | ~20 gal |
| Max Speed | ~7.6 mph | ~11 mph | ~11 mph |
| Dimensions (L Ă— W Ă— H with bucket) | ~11.29 ft Ă— 6.01 ft Ă— 6.67 ft | ~11.46 ft Ă— 6.01 ft Ă— 6.67 ft | ~11.91 ft Ă— 6.01 ft Ă— 6.67 ft |
