Case 430 and 440 SkidSteer Loader Repair Manual
$32.00
| đźšś Equipment | |
|---|---|
| Brand | CASE |
| Type | SkidSteer Loader |
| Model | 430 and 440 |
| đź“„ Documents | |
| Type | Repair Manual |
| Series | Series 3 |
| Publication | 6-78960 |
| Language | English |
| Format | |
| No of Pages | 524 |
The Case 430 and 440 Skid Steer Loaders are mid-frame, high-performance machines engineered for demanding construction, landscaping, and agricultural applications. With powerful Case Family III engines and rated operating capacities from 2,000 to 2,200 lbs, these loaders deliver excellent lift capacity, breakout force, and versatility for attachment work.
The Case 430 is equipped with a naturally aspirated 445/M2 diesel engine and offers a 2,000 lb rated load with a standard hydraulic flow of 21 GPM at 3,000 psi. The Case 440 builds on this performance with a turbocharged 445T/M2 diesel engine producing up to 82 hp, raising the rated capacity to 2,200 lbs. Both models feature robust hydrostatic transmissions, high travel speeds of up to 12 mph, and heavy-duty chaincase drives designed for durability in tough working conditions. Compact dimensions and responsive controls make them well-suited for maneuvering in confined job sites.
The repair manual provides complete system coverage, including the engine, fuel, electrical, tracks, power train, brakes, hydraulics, and mounted equipment. Detailed schematic sets support accurate diagnostics, while step-by-step repair procedures, torque values, and service schedules ensure both technicians and owners can maintain factory-level reliability. With clear instructions and foldout diagrams, the manual is an essential tool for extending the service life of these loaders.
Key Highlights
- Case 430: Naturally aspirated diesel engine, 2,000 lb rated operating capacity
- Case 440: Turbocharged diesel engine, 82 hp, 2,200 lb rated operating capacity
- Hydraulic system: 21 GPM flow at 3,000 psi for strong attachment performance
- Operating weights: 430 at 6,875 lbs, 440 at 6,980 lbs
- Travel speed up to 12 mph for fast cycle times and mobility
- Comprehensive repair manual covering engine, power train, hydraulics, brakes, and mounted equipment
- Includes full schematic set for electrical and hydraulic troubleshooting
- Designed for durability and easy service access with centralized maintenance points
Table of Content
đź“™ Table of Contents
Table Of Contents
- Table of Contents
General
- General
Engine
- Engine
Fuel System
- Fuel System
Electrical System
- Electrical System
Tracks
- Tracks
Power Train
- Power Train
Brakes
- Brakes
Hydraulics
- Hydraulics
Mounted Equipment
- Mounted Equipment
Schematic Set
- Schematic Set
Specification
| Specification | Case 430 Skid-Steer Loader | Case 440 Skid-Steer Loader |
|---|---|---|
| Engine Aspiration | Naturally aspirated (Family III 445/M2 Tier II) | Turbocharged (Family III 445T/M2 Tier II) |
| Displacement | 274 cu in (4.49 L) | 274 cu in (4.49 L) |
| Gross Power | Not specified | 82 hp (61 kW) @2300 rpm |
| Operating Weight | 6,875 lb (3,118 kg) | 6,980 lb (3,166 kg) |
| Fuel Capacity | 22 gal (83 L) | 22 gal (83 L) |
| Hydraulic Pump Flow | 21 gpm (79 L/min) | 21 gpm (79 L/min) |
| Relief Valve Pressure | 3,000 psi | 3,000 psi |
| Operating Load Rating | 2,000 lb (907 kg) | 2,200 lb (998 kg) |
| Bucket Capacity | 1 cu yd | 1 cu yd |
| Max Speed | 12 mph (19 km/h) | 12 mph (19 km/h) |
| Dimensions (L Ă— W Ă— H with bucket) | ~11 ft 5 in Ă— 6 ft 0 in Ă— 13 ft 6 in | ~10 ft 6 in Ă— 4 ft 4 in (width) Ă— 6.39 ft (height) |
