Case 1840 Skidsteer Repair Manual
$34.00
| 🚜 Equipment | |
|---|---|
| Brand | CASE |
| Type | Skidsteer |
| Model | 1840 |
| 📄 Documents | |
| Type | Repair Manual |
| Publication | 8-11653 |
| Language | English |
| Format | |
| No of Pages | 856 |
The Case 1840 Skid Steer Loader is one of the most popular and durable models produced by Case, known for its reliability, simplicity, and strong performance across a wide range of applications. Built with a 54 hp Case 4-390 diesel engine, the 1840 delivers 51 net horsepower and 179 lb·ft of torque, providing ample power for material handling, grading, and attachment operation. With a rated operating load of 1,400 lbs and a tipping load of 2,400 lbs, the 1840 is well-suited for construction, agriculture, and landscaping tasks requiring dependable lifting capacity and stability.
The hydraulic system delivers 15.3 GPM at 2,300 psi, ensuring efficient operation with a wide variety of attachments. Its hydrostatic drive provides smooth travel up to 6.2 mph, giving operators the ability to move quickly and efficiently on the job site. With an operating weight of over 5,200 lbs and a compact width of just under 5 ft, the 1840 combines maneuverability with rugged strength. A 19.5-gallon fuel tank ensures extended working hours without frequent refueling, while its straightforward mechanical design simplifies maintenance and repair.
The repair manual offers complete system coverage, including engines, fuel system, electrical, power train, hydraulics, mounted equipment, and rear pocket assemblies. It contains step-by-step repair procedures, torque specifications, lubrication charts, wiring diagrams, and hydraulic schematics to guide technicians through accurate servicing. Designed for long-term support, the manual ensures owners and operators can keep the 1840 performing at peak condition throughout its service life.
Key Highlights
- Case 4-390 4-cylinder diesel engine producing 54 gross hp (51 net hp)
- Rated operating load: 1,400 lbs with a tipping load of 2,400 lbs
- Hydraulic system: 15.3 GPM at 2,300 psi for strong attachment performance
- Operating weight ~5,216–5,558 lbs for durability and stability
- Hydrostatic drive with travel speed up to 6.2 mph
- Fuel capacity ~19.5 gallons for extended work cycles
- Compact dimensions: ~10.4 ft long, 4.8 ft wide, 6.4 ft high
- Repair manual coverage includes engine, hydraulics, power train, brakes, electrical, and mounted equipment
- Detailed wiring and hydraulic schematics for professional troubleshooting
Table of Content
📙 Table of Contents
Table Of Contents
- Table of Contents
General
- General
Engines
- Engines
Fuel System
- Fuel System
Electrical
- Electrical
Power Train
- Power Train
Hydraulics
- Hydraulics
Mounted Equipment
- Mounted Equipment
Rear Pocket
- Rear Pocket
Specification
| Specification | Case 1840 Skid-Steer Loader |
|---|---|
| Engine Model & Type | Case 4-390 diesel, 4-cylinder, direct injection |
| Displacement | 239 cu in (3.92 L) |
| Gross / Net Power | 54 hp gross / 51 hp net @ 2000 rpm |
| Peak Torque | 179 lb·ft @ 1200 rpm |
| Rated Operating Load | 1,400 lb (635 kg) |
| Operating Weight | ~5,216–5,558 lb |
| Hydraulic Pump Flow | 15.3 gpm (≈58 L/min) |
| Relief Valve Pressure | 2,300 psi |
| Travel Speed | ~6.2 mph (10 kph) |
| Fuel Capacity | ~19.5 gal (74 L) |
| Dimensions (L × W × H with bucket) | Length: ~10.44 ft · Width: ~4.79 ft · Height: ~6.44 ft |
