Case 1838 Uni-Loader SkidSteer Repair Manual
$33.00
| đźšś Equipment | |
|---|---|
| Brand | CASE |
| Type | Uni-Loader SkidSteer |
| Model | 1838 |
| đź“„ Documents | |
| Type | Repair Manual |
| Publication | 7-61690 |
| Language | English |
| Format | |
| No of Pages | 492 |
The Case 1838 Uni-Loader Skid Steer Loader is a versatile compact machine engineered for construction, agricultural, and landscaping applications where maneuverability and strength are essential. Powered by a reliable Kubota V2203DI-B 4-cylinder diesel engine delivering 49 gross horsepower (46 net hp), the 1838 provides the performance needed for heavy-duty tasks in a compact package. With a rated operating load of 1,325 lbs and a tipping load of 2,650 lbs, this model offers a strong balance between size, capacity, and stability.
Its hydraulic system delivers 15.8 GPM at 2,300 psi, enabling the use of a wide range of attachments for digging, lifting, grading, and material handling. The hydrostatic drive provides smooth power delivery, achieving travel speeds up to 6.5 mph for efficient job site performance. With an operating weight of just over 5,200 lbs and compact dimensions under 5 ft wide, the 1838 is well-suited for confined job sites without sacrificing lifting or breakout power. A 19.5-gallon fuel capacity supports longer operation with fewer refueling stops.
The repair manual covers all key systems in depth, including the engine, fuel system, electrical system, power train, hydraulics, and mounted equipment. It provides step-by-step service instructions, detailed wiring and hydraulic schematics, lubrication charts, and torque specifications to support professional maintenance and accurate troubleshooting. With comprehensive coverage, this manual ensures owners and technicians can maintain factory-level performance and extend the working life of the Case 1838.
Key Highlights
- Kubota 4-cylinder diesel engine producing 49 gross hp (46 net hp)
- Rated operating load: 1,325 lbs with a tipping load of 2,650 lbs
- Operating weight of ~5,216 lbs for stability and durability
- Hydraulic system: 15.8 GPM at 2,300 psi
- Travel speed up to 6.5 mph for efficient job site operation
- Compact dimensions: ~10.4 ft long, under 5 ft wide, and 77 in high
- Fuel capacity of ~19.5 gallons for extended run time
- Comprehensive repair manual coverage: engine, hydraulics, power train, electrical, and mounted equipment
- Includes wiring diagrams, hydraulic schematics, and service schedules for precise troubleshooting
Table of Content
đź“™ Table of Contents
Table Of Contents
- Table of Contents
General
- General
Engine
- Engine
Fuel System
- Fuel System
Electrical
- Electrical
Power Train
- Power Train
Hydraulics
- Hydraulics
Mounted Equipment
- Mounted Equipment
Specification
| Specification | Case 1838 Uni-Loader Skid-Steer |
|---|---|
| Engine Manufacturer & Model | Kubota V2203DI-B, 4-cylinder diesel |
| Gross / Net Power | 49 hp gross / 46 hp net |
| Rated Operating Load | 1,325 lb (601 kg) |
| Tipping Load | 2,650 lb (1,202 kg) |
| Operating Weight | ~5,216 lb |
| Hydraulic Pump Flow | 15.8 gpm |
| Relief Valve Pressure | 2,300 psi |
| Max Travel Speed | 6.5 mph |
| Fuel Capacity | ~19.5 gal |
| Dimensions (L Ă— W Ă— H w/ bucket) | Length with bucket: ~10.44 ft Width over tires: ~4.99 ft Height to top of ROPS: ~77.2 in |
