Case 1816, 1816B, 1816C Uni-Loader SkidSteer Repair Manual
$33.00
| đźšś Equipment | |
|---|---|
| Brand | CASE |
| Type | Uni-Loader SkidSteer |
| Model | 1816, 1816B, 1816C |
| đź“„ Documents | |
| Type | Repair Manual |
| Publication | 8-410105 |
| Language | English |
| Format | |
| No of Pages | 598 |
The Case 1816, 1816B, and 1816C Uni-Loader Skid Steer Loaders are compact, reliable machines designed for light construction, agriculture, and material-handling tasks. Produced between 1973 and 1985, these early-generation Uni-Loaders earned a reputation for simplicity, maneuverability, and ease of service. With rated operating loads of 700 lbs, they were ideal for small-scale projects, barn work, and confined job sites where larger machines could not operate efficiently.
The Case 1816 featured a Tecumseh HH160 gasoline engine delivering about 16 hp, while the 1816B upgraded to a Tecumseh OH160 with similar output but improved reliability. The 1816C advanced further with an Onan B43M gasoline engine, maintaining 16 hp but paired with enhanced durability and slightly greater weight for added stability. All three models shared an 8 GPM hydraulic system operating at 1,150 psi, providing consistent performance for their compact size. Weights ranged from approximately 1,874 lbs for the 1816B to just over 2,065 lbs for the 1816C.
The repair manual provides complete coverage of all systems, including engines, fuel system, electrical components, power train, brakes, hydraulics, and mounted equipment/chassis. Detailed step-by-step service procedures, wiring diagrams, hydraulic schematics, torque values, and lubrication schedules are included to ensure accurate maintenance and reliable operation. This manual is an essential resource for owners and technicians preserving these classic Uni-Loader machines.
Key Highlights
- Case 1816: Tecumseh HH160 gasoline engine, ~16 hp, 700 lb rated load, ~2,000 lb operating weight
- Case 1816B: Tecumseh OH160 gasoline engine, ~16 hp, 700 lb capacity, ~1,874 lb operating weight
- Case 1816C: Onan B43M gasoline engine, ~16 hp, 700 lb capacity, ~2,065 lb operating weight
- Hydraulic system: 8 GPM at 1,150 psi across all models
- Compact design optimized for maneuverability in tight workspaces
- Manual coverage includes engine, hydraulics, brakes, power train, and electrical systems
- Step-by-step repair instructions with schematics and diagrams
- Durable and easy-to-maintain early-generation Case Uni-Loader series
Table of Content
đź“™ Table of Contents
Table Of Contents
- Table of Contents
General
- General
Engines
- Engines
Fuel System
- Fuel System
Electrical
- Electrical
Power Train
- Power Train
Brakes
- Brakes
Hydraulics
- Hydraulics
Mounted Equipment/ Chassis
- Mounted Equipment/ Chassis
Specification
| Specification | Case 1816 Uni-Loader | Case 1816B Uni-Loader | Case 1816C Uni-Loader |
|---|---|---|---|
| Years Produced | 1973 – 1977 | 1977 – 1981 | 1981 – 1985 |
| Engine Manufacturer & Type | Tecumseh HH160, gasoline | Tecumseh OH160, gasoline | Onan B43M, gasoline |
| SAE Net Horsepower | ~16 hp | ~16 hp | ~16 hp |
| Hydraulic Pump Output | 8 gpm | 8 gpm | 8 gpm |
| Main Relief Pressure | 1,150 psi | 1,150 psi | 1,150 psi |
| Rated Operating Load | 700 lb | 700 lb | 700 lb |
| Operating Weight | ~2,000 lb | ~1,874 lb | ~2,065 lb |
| Travel Speed | ~12 km/h | ~12 km/h | — |
