Introduction

This shop manual is designed to give you a clear, hands-on guide to every major component group, breaking each chapter into four easy-to-follow sections:

• Structure and Function – how each part is built and works, laying the groundwork for effective troubleshooting

• Testing and Adjusting – the checks and calibrations to perform before and after repairs

• Disassembly and Assembly – step-by-step removal and reinstallation procedures, with all key precautions

• Maintenance Standard – the criteria you use to inspect parts and decide whether they meet service limits

Use these four sections as your roadmap in the workshop—start with “Structure and Function” to understand the component, move on to “Testing and Adjusting” to verify performance, follow “Disassembly and Assembly” for the actual repair work, and finish with “Maintenance Standard” to confirm everything is within spec.
